Apollo

ENVIRONMENTALLY FRIENDLY

Eco-friendly R410A refrigerant

QUIET

Quiet mode fan speed setting provides super quiet operation

SELECT YOUR COMFORT

5 levels of adjustable air volume

POWERFUL COOLING

Expansive air distribution up to 12 meters

SMART DISPLAY

Shows the room temperature on LED screen

WARRANTY

Compressor warranty 5 years and WARRANTY OF PARTS 1 year

FILL YOUR SPACE WITH COOLNESS

Intelligent Cooling

Carefully designed in every aspect to spread the coolness to every corner of your space, APOLLO air conditioner offers more than powerful cooling and energy saving, additionally it limits the noise and gives you the ultimate cooling for every inch of your space and for the best result to match with all usability perfectly. Cooling with Carrier ensures you to have the exclusive sensational experience of cooling.

LEADER OF COMFORT

Discover the Essence of Delightful Life

Spending your valuable time together with your loved ones is the chance to create significant memories each second and make your life meaningful, this is what Carrier has experience over 117 years, we learn all the needs of your special area. Carrier is dedicated to provide favorable climate in your place of life, work, relax and joy, offering state-of-the-art technology that is quiet, easy to use, reliable and energy efficient.

VERSATILITY

2 Steps Cleaning System

Activated Carbon Filter is intelligent filter with bamboo charcoal designed to effectively neutralize contaminants, such as allergens, viruses and bacteria, ensuring the circulation of fresh, clean air in your space.

FILL YOUR SPACE WITH COOLNESS

Intelligent Cooling

LEADER OF COMFORT

Discover the Essence of Delightful Life

VERSATILITY

2 Steps Cleaning System

The size of this BTU model.

13,000 BTU
18,700 BTU
26,400 BTU
31,000 BTU
37,000 BTU
36,200 BTU
40,900 BTU
48,000 BTU
48,000 BTU
54,000 BTU
60,000 BTU

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
13,000

SEER
13.81 Btu/Hr./Watt

Power Consumption
1.00 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
10,869.24 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE004-R1

Air Flow Rate (H/M/L)
CFM – 400

Noise level (H/M/L)
39 / 37 / 33 / 30 / 28 dB (A)

Dimension (HxWxD)
235 x 1,106 x 680 mm.

Net Weight
25 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE013-R1

Noise Level
49 dB(A)

Dimension (HxWxD)
550 x 718 x 285 mm

Weight
36 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
15 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
18,700

SEER
12.98 Btu/Hr./Watt

Power Consumption
1.53 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
16,658.84 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE006-R1

Air Flow Rate (H/M/L)
CFM – 600

Noise level (H/M/L)
44 / 41 / 36 / 32 / 30 dB (A)

Dimension (HxWxD)
235 x 1,106 x 680 mm.

Net Weight
27 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE018-R1

Noise Level
58 dB(A)

Dimension (HxWxD)
550 x 870 x 285 mm

Weight
40 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
26,400

SEER
12.98 Btu/Hr./Watt

Power Consumption
1.26 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
23,518.37 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE008-R1

Air Flow Rate (H/M/L)
CFM – 800

Noise level (H/M/L)
48 / 46 / 42 / 38 / 35 dB (A)

Dimension (HxWxD)
235 x 1,290 x 680 mm.

Net Weight
33 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE025-R1

Noise Level
59 dB(A)

Dimension (HxWxD)
777 x 840 x 330 mm

Weight
56 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
31,000

SEER
12.76 Btu/Hr./Watt

Power Consumption
2.58 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
28,092.41 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE010-R1

Air Flow Rate (H/M/L)
CFM – 1,000

Noise level (H/M/L)
52 / 48 / 46 / 42 / 38 dB (A)

Dimension (HxWxD)
235 x 1,290 x 680 mm.

Net Weight
35 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE030-R1

Noise Level
59 dB(A)

Dimension (HxWxD)
980 x 970 x 340 mm

Weight
76 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
37,000

SEER
12.51 Btu/Hr./Watt

Power Consumption
3.14 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
34,199.71 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE012-R1

Air Flow Rate (H/M/L)
CFM – 1,200

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
43 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE036-R1

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
36,200

SEER
12.65 Btu/Hr./Watt

Power Consumption
3.04 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
33,089.94 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE012-R3

Air Flow Rate (H/M/L)
CFM – 1,200

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
43 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE036-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
PMV (Pulse Motor Valve)

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
40,900

SEER
12.48 Btu/Hr./Watt

Power Consumption
3.48 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
37,895.42 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE014-R3

Air Flow Rate (H/M/L)
CFM – 1,400

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE040-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
83 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
48,000

SEER
10.30 Btu/Hr./Watt

Power Consumption
4.95 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
53,886.75 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE016-R3

Air Flow Rate (H/M/L)
CFM – 1,600

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
46 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE048-R3

Noise Level
59 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
48,000

SEER
10.73 Btu/Hr./Watt

Power Consumption
4.75 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
51,727.26 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE016-S3

Air Flow Rate (H/M/L)
CFM – 1,600

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE048-S3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
86 kg

Refrigerant
R410a

Compressor Type
Scroll

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
54,000

SEER
10.28 Btu/Hr./Watt

Power Consumption
6.20 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
67,489.49 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE020-R3

Air Flow Rate (H/M/L)
CFM – 2,000

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
46 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE060-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,340 x 970 x 340 mm

Weight
88 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
60,000

SEER
10.71 Btu/Hr./Watt

Power Consumption
5.95 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
67,489.49 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE020-R3

Air Flow Rate (H/M/L)
CFM – 2,000

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE060-S3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,340 x 970 x 340 mm

Weight
90 kg

Refrigerant
R410a

Compressor Type
Scroll

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

13,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
13,000

SEER
13.81 Btu/Hr./Watt

Power Consumption
1.00 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
10,869.24 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE004-R1

Air Flow Rate (H/M/L)
CFM – 400

Noise level (H/M/L)
39 / 37 / 33 / 30 / 28 dB (A)

Dimension (HxWxD)
235 x 1,106 x 680 mm.

Net Weight
25 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE013-R1

Noise Level
49 dB(A)

Dimension (HxWxD)
550 x 718 x 285 mm

Weight
36 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
15 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
18,700 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
18,700

SEER
12.98 Btu/Hr./Watt

Power Consumption
1.53 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
16,658.84 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE006-R1

Air Flow Rate (H/M/L)
CFM – 600

Noise level (H/M/L)
44 / 41 / 36 / 32 / 30 dB (A)

Dimension (HxWxD)
235 x 1,106 x 680 mm.

Net Weight
27 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE018-R1

Noise Level
58 dB(A)

Dimension (HxWxD)
550 x 870 x 285 mm

Weight
40 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
26,400 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
26,400

SEER
12.98 Btu/Hr./Watt

Power Consumption
1.26 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
23,518.37 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE008-R1

Air Flow Rate (H/M/L)
CFM – 800

Noise level (H/M/L)
48 / 46 / 42 / 38 / 35 dB (A)

Dimension (HxWxD)
235 x 1,290 x 680 mm.

Net Weight
33 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE025-R1

Noise Level
59 dB(A)

Dimension (HxWxD)
777 x 840 x 330 mm

Weight
56 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
Capillary Tube

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
31,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
31,000

SEER
12.76 Btu/Hr./Watt

Power Consumption
2.58 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
28,092.41 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE010-R1

Air Flow Rate (H/M/L)
CFM – 1,000

Noise level (H/M/L)
52 / 48 / 46 / 42 / 38 dB (A)

Dimension (HxWxD)
235 x 1,290 x 680 mm.

Net Weight
35 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE030-R1

Noise Level
59 dB(A)

Dimension (HxWxD)
980 x 970 x 340 mm

Weight
76 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
37,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
37,000

SEER
12.51 Btu/Hr./Watt

Power Consumption
3.14 Kw

Power Supply
220 V / 1 Phase / 50 Hz

Estimated Electricity Charge*
34,199.71 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE012-R1

Air Flow Rate (H/M/L)
CFM – 1,200

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
43 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE036-R1

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
36,200 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
36,200

SEER
12.65 Btu/Hr./Watt

Power Consumption
3.04 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
33,089.94 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE012-R3

Air Flow Rate (H/M/L)
CFM – 1,200

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
43 kg.

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE036-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Expansion Device Valve
PMV (Pulse Motor Valve)

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
40,900 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
40,900

SEER
12.48 Btu/Hr./Watt

Power Consumption
3.48 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
37,895.42 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE014-R3

Air Flow Rate (H/M/L)
CFM – 1,400

Noise level (H/M/L)
49 / 46 / 44 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE040-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
83 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
48,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
48,000

SEER
10.30 Btu/Hr./Watt

Power Consumption
4.95 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
53,886.75 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE016-R3

Air Flow Rate (H/M/L)
CFM – 1,600

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
46 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE048-R3

Noise Level
59 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
84 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
48,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
48,000

SEER
10.73 Btu/Hr./Watt

Power Consumption
4.75 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
51,727.26 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE016-S3

Air Flow Rate (H/M/L)
CFM – 1,600

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE048-S3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,250 x 970 x 340 mm

Weight
86 kg

Refrigerant
R410a

Compressor Type
Scroll

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
54,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
54,000

SEER
10.28 Btu/Hr./Watt

Power Consumption
6.20 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
67,489.49 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE020-R3

Air Flow Rate (H/M/L)
CFM – 2,000

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
46 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE060-R3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,340 x 970 x 340 mm

Weight
88 kg

Refrigerant
R410a

Compressor Type
Rotary

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)
60,000 BTU: APOLLO

Ceiling

SPECIFICATION

Cooling Capacity (BTU/hr)
60,000

SEER
10.71 Btu/Hr./Watt

Power Consumption
5.95 Kw

Power Supply
380 V / 3 Phase / 50 Hz

Estimated Electricity Charge*
67,489.49 Baht/yr

Compare Products

INDOOR UNIT MODEL

Model Name
42FCE020-R3

Air Flow Rate (H/M/L)
CFM – 2,000

Noise level (H/M/L)
52 / 50 / 46 / 41 / 38 dB (A)

Dimension (HxWxD)
235 x 1,614 x 680 mm.

Net Weight
45 kg.

Expansion Device Valve
Capillary Tube

Capacity Test Condition
27° Cdb, 19° Cwb

OUTDOOR UNIT MODEL

Model Name
38FCE060-S3

Noise Level
58 dB(A)

Dimension (HxWxD)
1,340 x 970 x 340 mm

Weight
90 kg

Refrigerant
R410a

Compressor Type
Scroll

Minimum Pipe Length
3 M.

Maximum Pipe Length
30 M.

Capacity Test Condition
35° Cdb, 24° Cwb

*Refer to energy label No.5 by Electricity Generating Authority of Thailand (EGAT)

Consult detailed product information about this model anytime, anywhere on your personal computer or tablet device.

Product manuals download

E-brochure download

Consult detailed product information about this model anytime, anywhere on your personal computer or tablet device.

Product manuals download

E-brochure download

Consult detailed product information about this model anytime, anywhere on your personal computer or tablet device.

Product manuals download

E-brochure download
